Description
Description:
Nitobond PC thixotropic epoxy adessive is a 2-pack solvent free epoxy resin system consisting of a white base, black
hardener in reweighed quantities for easy onsite mixing. The product is available in three grades:
- Nitobond PC20 – Fast set for application between 50C t0 200 C
- Nitobond PC 30 – Medium Fast set for application between 150C to 300C
- Nitobond PC40 – Slow set for application between 250C to 400C
Uses:
Bonding segmented concrete bridges to speed up construction and provide a structural and water-resistant joint.
Can be used for pointing Stone masonry joints to retain structural integrity.
Advantages:
- Excellent squeezability
- High bond strength
- Fast cure
- Tolerant to damp surfaces
- Wide range temperature applications
Standards compliance:
Nitobond PC meets the FIP specifications in all respects.
Technical Support:
The company provides a technical advisory service supported by a team of specialists in the field.
Properties
Color Base – White
Hardener – Black
Mixed – Grey
Application instructions
Surface Preparation
Concrete should be mechanically sound and free from contamination, such as free water, Mould, oil or grease, laitance and dust. Grit blasting is recommended. Sections to be bonded should be checked for good alignment. A ‘dry run’ before the first application of the adhesive is recommended to ensure correct timing.
Mixing:
The base and hardener into a suitable container shall be emptied and mix with a paddle and slow speed heavy duty
drill, ensuring the sides are scraped down. A uniform grey color should be obtained after mixing thoroughly.
Application:
The mixed adhesive is applied to both surfaces to be bonded with a serrated trowel or other suitable spreader.
The joint should be closed immediately, if this is not achieved the surface of the adhesive should be slightly scratched
immediately prior to closing the joint to expose fresh adhesive. The joint must be closed within the open time of the adhesive. On site monitoring of the operation using lapped asbestos cement panels is recommended.
Cleaning of Application Equipment:
Tools and equipment should be cleaned immediately after use with Nitoflor Sol.
Estimating
Packaging
30 Ltr. bulk packs and 3.7 L standard packs.
Coverage:
Approximately 2 L/m2 at 2 mm thickness.
Storage:
At least 12 months if stored below 350C in unopened containers.
Precautions
Health and Safety
Some people are sensitive to epoxy resin system and may develop dermatitis. Direct contact with eyes will cause irritation
and may cause serious damage if left untreated. Any eye contamination should be washed thoroughly with water and
immediate medical attention should be sought. Gloves, barrier creams and eye protection should always be used when
handling Nitobond PC and Nitoflor Sol. If contact with skin occurs, a resin removing cream should be used, followed by washing with soap and water. Solvent shall not be used.
Fire:
Nitobond PC base and hardener are nonflammable. Nitoflor Sol is flammable. Do not use near naked flames. No smoking.
Additional information:
Nitobond PC is part of a wide range of adhesives, repair materials, sealing and waterproofing compounds, grouts and
flooring products manufactured by Fosroc for the construction industry. Separate data is available on these products.
Important note:
Fosroc products are guaranteed against defective materials and manufacture and are sold subject to its standard terms and conditions of sale, copies of which may be obtained on request. Whilst Fosroc endeavors to ensure that any advice, recommendation specification or information it may give is accurate and correct, it cannot, because it has no direct or continuous control over where or how its products are applied, accept any liability either directly or indirectly arising from the use of its products whether or not in accordance with any advice, specification, recommendation or information given by it.
